AI Agents and Tool Use 🤖

Deepika, 16, from Lucknow spent three hours every day doing research for her school debates — searching Google, reading papers, taking notes, summarising. "Can I automate this?" she wondered after Lesson 7.

A regular ChatGPT prompt wouldn't work — it couldn't search the web or read PDFs. She needed an agent: a system that could decide what tools to use, use them in sequence, and synthesise the results into an answer.

Using LangGraph and OpenAI's tool-calling API, she built a research agent in 150 lines of Python. It searches arXiv, reads abstracts, cross-references sources, and writes a structured summary. What used to take 3 hours now takes 3 minutes. She now uses those 3 hours to actually understand the papers.

A chatbot answers one question per turn. An agent can take multiple actions autonomously to complete a goal. It has three components:

• Perceive: Read the current state — user request, previous actions, tool outputs
• Plan: Decide what to do next — which tool to use, or whether to give a final answer
• Act: Execute the tool call or produce the final response

The ReAct (Reason + Act) pattern alternates between thinking (generating a reasoning trace) and acting (calling tools), enabling the agent to use tool outputs to inform its next reasoning step.

import openai, json

client = openai.OpenAI()

# ── Define tools as JSON schemas ──────────────────────────────────
tools = [
    {
        "type": "function",
        "function": {
            "name": "search_web",
            "description": "Search the web and return top 3 relevant results",
            "parameters": {
                "type": "object",
                "properties": {
                    "query": {
                        "type": "string",
                        "description": "The search query"
                    }
                },
                "required": ["query"]
            }
        }
    },
    {
        "type": "function",
        "function": {
            "name": "calculate",
            "description": "Evaluate a mathematical expression safely",
            "parameters": {
                "type": "object",
                "properties": {
                    "expression": {
                        "type": "string",
                        "description": "Python math expression e.g. '2**10 + 5*3'"
                    }
                },
                "required": ["expression"]
            }
        }
    }
]

# ── Implement the actual tools ─────────────────────────────────────
def search_web(query: str) -> str:
    """Stub — replace with SerpAPI, Tavily, or DuckDuckGo API."""
    return f"Search results for '{query}': [3 relevant web snippets]"

def calculate(expression: str) -> str:
    """Safe math evaluation — no exec/eval of arbitrary code."""
    import ast, math
    try:
        # Only allow safe nodes
        tree = ast.parse(expression, mode='eval')
        # Whitelist: numbers, operators, basic math functions
        allowed_nodes = {
            ast.Expression, ast.BinOp, ast.UnaryOp, ast.Num,
            ast.Add, ast.Sub, ast.Mult, ast.Div, ast.Pow,
            ast.USub, ast.UAdd, ast.Constant
        }
        for node in ast.walk(tree):
            if type(node) not in allowed_nodes:
                return "Error: unsafe expression"
        result = eval(compile(tree, "", "eval"))
        return str(result)
    except Exception as e:
        return f"Error: {e}"

TOOL_MAP = {"search_web": search_web, "calculate": calculate}

# ── Agent loop ─────────────────────────────────────────────────────
def run_agent(user_message: str) -> str:
    messages = [
        {"role": "system", "content": "You are a helpful research assistant. Use tools to find accurate information."},
        {"role": "user", "content": user_message}
    ]

    for _ in range(10):   # max 10 reasoning steps
        response = client.chat.completions.create(
            model="gpt-4o-mini",
            messages=messages,
            tools=tools,
            tool_choice="auto"
        )

        msg = response.choices[0].message

        # If no tool call: agent has a final answer
        if not msg.tool_calls:
            return msg.content

        # Execute each tool call
        messages.append(msg)
        for tc in msg.tool_calls:
            fn_name = tc.function.name
            fn_args = json.loads(tc.function.arguments)
            result  = TOOL_MAP[fn_name](**fn_args)

            messages.append({
                "role": "tool",
                "tool_call_id": tc.id,
                "content": result
            })

    return "Max steps reached"

print(run_agent("What is 2^10 and who wrote the Attention Is All You Need paper?"))

# External memory with ChromaDB (persistent across sessions)
# pip install chromadb

import chromadb

chroma = chromadb.PersistentClient(path="./agent_memory")
collection = chroma.get_or_create_collection("research_notes")

def remember(key: str, text: str):
    """Store a research note in vector memory."""
    collection.upsert(
        documents=[text],
        ids=[key]
    )

def recall(query: str, n=3) -> list[str]:
    """Retrieve most relevant past notes."""
    results = collection.query(query_texts=[query], n_results=n)
    return results['documents'][0]

# Usage:
remember("rag_2024", "RAG 2024: Corrective RAG paper shows 15% improvement over naive RAG...")
similar_notes = recall("what do I know about RAG?")
print(similar_notes)

# pip install langgraph langchain-openai

from typing import TypedDict, Annotated
from langgraph.graph import StateGraph, END
from langgraph.prebuilt import ToolNode
import operator

# ── Define agent state ─────────────────────────────────────────────
class AgentState(TypedDict):
    messages: Annotated[list, operator.add]
    step_count: int

# ── Nodes ──────────────────────────────────────────────────────────
from langchain_openai import ChatOpenAI
from langchain_core.tools import tool

@tool
def search_arxiv(query: str) -> str:
    """Search arXiv for papers on a topic."""
    return f"Papers found for '{query}': [arxiv results]"

@tool
def summarise_abstract(arxiv_id: str) -> str:
    """Get and summarise the abstract of an arXiv paper."""
    return f"Abstract summary for {arxiv_id}: [key findings]"

llm = ChatOpenAI(model="gpt-4o-mini").bind_tools([search_arxiv, summarise_abstract])

def agent_node(state: AgentState) -> AgentState:
    response = llm.invoke(state["messages"])
    return {"messages": [response], "step_count": state["step_count"] + 1}

def should_continue(state: AgentState) -> str:
    last = state["messages"][-1]
    if last.tool_calls:
        return "tools"
    return END

# ── Build graph ───────────────────────────────────────────────────
tool_node = ToolNode([search_arxiv, summarise_abstract])

graph = StateGraph(AgentState)
graph.add_node("agent", agent_node)
graph.add_node("tools", tool_node)
graph.set_entry_point("agent")
graph.add_conditional_edges("agent", should_continue)
graph.add_edge("tools", "agent")   # after tools, return to agent

app = graph.compile()

# ── Run ───────────────────────────────────────────────────────────
result = app.invoke({
    "messages": [{"role": "user", "content": "Find 3 key papers on RAG from 2024 and summarise each"}],
    "step_count": 0
})
print(result["messages"][-1].content)
